Modular handheld test solution for all-in-one Access/FTTx network and triple-play services installation and maintenance.
All-in-one Access/FTTx/Triple-Play Services Test Set
The MTS-4000 is a small, compact and handheld test platform designed for all phases of the network lifecycle, from the installation to the maintenance of Access/FTTx networks and triple-play services. Modular in design, the MTS-4000 offers field service technicians the highest performance and superior levels of scalability and upgradeability.
-Large 7-inch indoor/outdoor color display
-Cost-effective, compact and handheld platform
-Multi-layer network solution from physical to services layer
-Highly scalable with up to 2 field-replaceable modules
-Connection checker with VFL, power meter and video inspection scope options
-Flexible connectivity for fast data transfer: 2xUSB 2.0, up to 1 Gb/s Ethernet
-Fiber test applications include OTDR, PON meter, video inspection scope, laser source/power meter, and VFL
-Copper test applications include volt/ohm meter, time domain reflectometer (TDR), resistive fault locator, and wideband tones/spectal analysis to 30 MHz
-Triple-play service testing/IPTV and VoIP measurements from DSL access interfaces or standard Ethernet port
-VDSL and ADSL testing using Infineon Technologies chipset and licensed option for Dr. DSL?diagnostic solutions from Aware, Inc.
-Lightweight platform: only 1.4kg/3 lbs
-Intuitive graphical user interface with touchscreen option
-Extended battery life using smart Lithium ion cell
-Scripting capability for automation, simplification and automatic data reporting
-Easy Internet access via installed web browser
-Remote control access allowing remote assistance from any expert user
-Integration of basic applications such as HTML and PDF reader
-Comprehensive suite of PC software tools for post-processing of test results with FiberTrac (OFS-100) and FiberCale (OFS-200)
